Electrical Troubleshooting Quiz — April 7, 2020
On the Line 7 drying oven, one of the motors was replaced for the first time in 15 years. That was 18 months ago, and three replacements have been made since then.
The motor has a variable speed drive, and the drive has been thoroughly checked and ruled out as a possible cause. Voltage imbalance, low voltage, high voltage, voltage distortion, and excess harmonic distortion have all been ruled out as well. A portable power analyzer was hung on the branch circuit after the second failure, and it recorded no transient events during that time.
One theory was that a bonding jumper was missing so undesired current flowed through the motor casing; that, too, was ruled out. Can you solve this?
Are you sure it's the right replacement motor? Perhaps the wrong motor data got entered in the computerized maintenance management system (CMMS). Go back to the original drawings and specs to find which motor should be installed. It's on a drying oven, and that's a good clue. The original motor was probably temperature-rated, and maybe that rating did not get entered in along with the other motor data. Thus, after a few months, the motor insulation fails.
What is the failure mode? If it's bearing failure, the problem is most likely incorrect lubrication. If it's insulation failure and the replacements match the original spec, determine if something has changed with the drying oven to require a higher temperature rating.
Another place to look is at the replacements. Where are these coming from? Have they been properly stored? Does anyone take baseline test data on them, or even test them at all before installation?
