Code Q&A: Sizing Branch Circuits for Appliances

Dec. 9, 2021

Test your Code knowledge.

Based on the 2020 NEC.

Q. What is the Code requirement for branch circuit sizing for appliances?

See answer below.

A. The ampacities of branch-circuit conductors for an individual appliance are not permitted to be less than the branch-circuit rating marked on the appliance (Sec. 422.10). Author’s Comment: Listed appliances come with installation instructions from the manufacturer, and sometimes the minimum overcurrent protection and or conductor size are marked on the appliance.

Branch-circuit conductors for household ranges and cooking appliances are sized per Table 220.55 and Sec. 210.19(A)(3).

Branch circuits supplying appliances in addition to other loads must be sized per Sec. 210.23(A) as follows:

A 15A or 20A branch circuit cord-and-plug-connected equipment is not permitted to be rated more than 80% of the branch-circuit ampere rating [Sec. 210.23(A)(1)].
A 15A or 20A branch circuit equipment fastened in place is not permitted to be rated more than 50% of the branch-circuit ampere rating, if the circuit supplies both luminaires and receptacles [Sec. 210.23(A)(2)].
