Code Q&A: NEC Requirements for Expansion Fittings on PVC Raceways

Dec. 28, 2023
Test your knowledge of the NEC.

Courtesy of www.MikeHolt.com

Q. What is the NEC requirement for expansion fittings on PVC raceways?

See answer below.





A. As stated in Sec. 352.44, if PVC conduit is installed in a straight run between securely mounted items such as boxes, cabinets, elbows, or other conduit terminations, expansion fittings must be provided if the expansion or contraction length change (in accordance with Table 352.44) is expected to be ¼ in. or greater.

Author's comment: When determining the number and setting of expansion fittings, you must read the manufacturer’s documentation. For example, instructions for Carlon expansion fittings for PVC conduit say that when it has sunlight exposure, 30ºF must be added to the high ambient temperature.

These materials are provided to us by Mike Holt Enterprises in Leesburg, Fla. To view Code training materials offered by this company, visit www.mikeholt.com/code.
