Code Quiz: Protection of Fixed Industrial Process Heating Equipment
Based on the 2020 NEC.
Question: What is the maximum size permitted for protection of resistance type heating elements in a fixed industrial process?
See answer below.
Answer: 150A
Explanation: In the 2020 NEC, Sec. 425.22(B) was revised to allow heating elements to be subdivided into circuits of 120A and protected at 150A if the one of the following conditions are met:
- Elements are integral with and enclosed within a process heating surface
- Elements are completely contained within an enclosure identified as suitable for this use
- Elements are contained within an ASME-rated and stamped vessel
If the installation does not meet one of the three listed conditions, the previous rules of elements subdivided into 48A circuits protected at not more than 60A would apply.
Lupacchino is a senior design engineer with Gaylor Electric, Inc. in Noblesville, Ind. and serves as an alternate on NEC Code-Making Panel No. 3. He is currently licensed in more than 80 jurisdictions. He can be reached at [email protected].
