Code Q&A: Accounting for Thermal Expansion of Cable Tray

Test your NEC knowledge.

Sept. 9, 2021

Based on the 2020 NEC.

Q. What does the Code require to compensate for the thermal expansion of a cable tray?

See answer below.

A. Expansion splice plates for cable trays must be provided where necessary to compensate for thermal expansion and contraction [Sec. 392.44]. Thermal expansion is often overlooked and can be a problem without the installation of raceway expansion joints. For the raceway to properly serve its function, it must be able to expand, as well as contract, and expansion joints provide the ability to do so.

This Code section gives no guidance on how to determine the need for an expansion splice plate but there is a National Electrical Manufacturer’s Association (NEMA) document available as a free download that may assist. This document is titled; “NEMA VE2, Cable Tray Installation Guidelines.”

These materials are provided to us by Mike Holt Enterprises in Leesburg, Fla. To view Code training materials offered by this company, visit www.mikeholt.com/code.
