Code Q&A: NEC Requirement for AC Cable Bends

Oct. 24, 2024
Test your knowledge of the NEC with this challenging question.

Courtesy of www.MikeHolt.com. Based on the 2023 NEC.

Question: The radius of the curve of the inner edge of any bend shall not be less than _____ for AC cable.

a) five times the largest conductor within the cable

b) three times the diameter of the cable

c) five times the diameter of the cable

d) six times the outside diameter of the conductors

See answer below.









Answer: c) five times the diameter of the cable

Section 320.24 states, "Bends in Type AC cable shall be made such that the cable is not damaged. The radius of the curve of the inner edge of any bend shall not be less than five times the diamater of the Type AC cable."

These materials are provided by Mike Holt Enterprises in Leesburg, Fla. To view Code training materials offered by this company, visit www.mikeholt.com/code.
